Specifcations
| Items | Parameter | |||||||||||
| Product model | L-FI3 | L-FI4 | L-FI5 | L-FI6 | ||||||||
| Pixel pitch | PH3 | PH4 | PH5 | PH6 | ||||||||
| Cabinet Size | 576*576mm | 768X768mm | 640X640mm | 768X768mm | ||||||||
| Resolution/cabinet | 192(W)*192(H) | 192(W)*192(H) | 128(W)*128(H) | 128(W)*128(H) | ||||||||
| Pixel density | 111111 Pixel/㎡ | 62500Pixel/㎡ | 40000 Pixel/㎡ | 27777 Pixel/㎡ | ||||||||
| Scan model | 1/16 Scan | 1/16 Scan | 1/16 Scan | 1/8 Scan | ||||||||
| refresh frequency | ≥1000Hz | |||||||||||
| Beam Angle | Horizontal 130° Vertical 120° | |||||||||||
| Best viewing distance | ＞3m | ＞4m | ＞5m | ＞6m | ||||||||
| Power consumption | 380W/㎡ | 300W/㎡ | 146W/㎡ | 200W/㎡ | ||||||||
| Lifetime | ＞50000hours | ＞50000hours | ＞50000hours | ＞50000hours | ||||||||
| IP Rate | IP44 | IP44 | IP44 | IP44 | ||||||||
| Net Weight | 15Kg/pc | 22Kg/pc | 18Kg/pc | 22Kg/pc | ||||||||
